Carril 48V Track 48V Rece L

B32 / B34 / B35: 4-wire rail, with two options for use: option 2 circuits (2x +/-15A/0-60V dc) or option 1 circuit (+/-15A/0-60V )+ Data Bus (D+/D-) . The DC voltage connection is 48V. The rail can support 25kg with a distance between fixings of 0.9m. B33: Double rail 8 conductors, 4 on top and 4 on bottom. On each side, with two options for use: option 2 circuits (2x +/-15A/0-60V dc) or option 1 circuit (+/-15A/0-60V )+ Data Bus (D+/D-). The DC voltage connection is 48V. The rail can support 25kg with a distance between fixings of 0.9m.
